Product user manual
DBE-1200S
Modules available for the DBE-1200S
Upstream (US)
DBUS-C-1 Main module: 204 MHz US amplifier 26 dB gain and IDS
DBUS-D-1 Bridger module: 204 MHz upstream amplifier 26 dB gain and IDS
Downstream (DS)
DBDS-B-4-1 Main: 1.2 GHz DS amplifier 44 dB - 49 dbmV output
DBDS-B-4-ET Main: 1.2 GHz DS amplifier 44 dB - 49 dbmV output – ET:25 dB tilt
DBDS-B-5-1 Main: 1.2 GHz DS amplifier 38 dB - 49 dbmV output
DBDS-B-6-1 Main: 1.2 GHz DS amplifier 32 dB - 49 dbmV output
DBDS-B-7-1 Main: 1.2 GHz DS amplifier 44 dB - 53 dbmV output
DBDS-B-7-ET Main: 1.2 GHz DS amplifier 44 dB - 53 dbmV output ET:25 dB tilt
DBDS-F-2 Bridger: 1.2 GHz downstream amplifier 44 dB - I2C
DBDS-F-5-1 Bridger: 1.2 GHz downstream amplifier 44 dB - I2C - 53 dBmV output
Control Module
DBDCM-A-1 AGC/ALSC, FSK
DBDCM-B-2 AGC/ALSC, DOCSIS transponder compatible
DBDDM-A-1 DOCSIS 3.0 transponder
DBDDM-B-1 EuroDOCSIS 3.0 transponder
Optical Modules
R
DBRX-A-1 Optical 1.2 GHz downstream receiver, 53 dBmV output
TX
DBTX-A-1 Optical upstream transmitter module. Holds up to 2 DBLB optical transmitters
DBLB-31-3D-1 Optical 204 MHz transmitter plug-in, 1310 nm, DFB, 3 dBm output, SC/APC
DBLB-55-3D-1 Optical 204 MHz transmitter plug-in, 1550 nm, DFB, 3 dBm output, SC/APC
DBLB-BP-1 Bypass laser board for DBTX-A-1 (insert in second slot if second laser is not installed)
DBLB-CB-1 Combiner board to combine two upstream RF signals into a single laser
