2 TECHNICOLOR GATEWAYS
This chapter describes the Technicolor TG789VAC v2 DSL gateway, which is one of the modems/gateways used by AT&T
on DSL connections.
2.1 Technicolor TG789VAC v2 gateway
The TG789VAC v2 is an Integrated multi-mode ADSL/VDSL/FTTH gateway, supporting:
• ADSL over POTS for a TG789VAC v2 ADSL/POTS variant (Plain Old Telephone Service), an analogue telephone
line.
• ADSL/RE-ADLS2/ADSL2/ADSL2+
• VDSL2 with Vectoring technology
• Support for FTTH via Gigabit-Ethernet WAN port
• Firmware 10.5.8.U and later
• Auto-sensing for ADSL/VDSL2 and switches between them
• 4 ports Gigabit-Ethernet auto-sensing port for LAN connections.
• An USB-port to connect to a workstation or 3G USB stick.
• 2 FXS ports and VOIP functionality.
• Wi-Fi IEEE 802.11b/g/n/ac, will not be used in standard configurations, can be enabled via GUI and external
software.
The TG789VAC v2 gateway is a versatile device, which can be configured as a bridge or a router (or gateway) to suit all
different DSL environments. It has a built-in firewall which makes it possible to protect the LAN-side or Home network
from unauthorized access from the Internet.
Illustration 2.1: Technicolor TG789VAC v2gateway
The TG789vn supports several features, which are not supported by AT&T:
• Printer server function
• USB 3G function
• Voice over IP
• IPTV
These functions have been disabled.
