Technics SA-C100 User Manual

114
Others
Specifications
(Continued)
■
GENERAL
Power supply
AC 220 V to 240 V,
50/60 Hz
Power consumption 46 W
Power consumption
in standby mode
(Network Standby
Off & No clock
display)
0.2 W
Power consumption
in standby mode
(Network Standby
On & No clock
display)
2.0 W
*
1
Dimensions
(W×H×D)
340 mm × 94 mm ×
341 mm
Mass Approx. 4.8 kg
Operating
temperature range
0 °C to 40 °C
Operating humidity
range
35 % to 80 % RH
(no condensation)
*
1: Wired LAN or Wireless LAN
■
AMPLIFIER SECTION
Output power
50 W + 50 W
(1 kHz, T.H.D. 1.0 %, 4 Ω,
20 kHz LPF)
Load Impedance 4 Ω - 16 Ω
Frequency Response
PHONO (MM)
20 Hz - 20 kHz
(RIAA DEVIATION ±1dB,
8 Ω)
LINE 20 Hz - 40 kHz (-3 dB, 8 Ω)
DIGITAL 20 Hz - 80 kHz (-3 dB, 8 Ω)
Input sensitivity/
Input impedance
LINE 650 mV / 31 kΩ
PHONO (MM) 6.5 mV / 47 kΩ
