Technics SX-PX554

Ref. No. Part No. Part Name & Description
Pcs
Remarks
25-4 QGKG0154AB ORNAMENT 1 SX-PX554M
25-5 QMRG7031EC PROTECTOR 1
25-6 QMRG7032EC PROTECTOR 1
25-7 QMFG1277AA FELT 2
25-8 QGKG0095AD ORNAMENT 1
26 QKQGN998AAZ CROSS BOARD 1
26 QKQGN998ABZ CROSS BOARD 1 SX-PX554M
27 SHRG9620A CORD CLAMPER 3
28 QKQGM107AAZ PANEL BOX ASS'Y 1
28 QKQGM105ABZ PEDAL BOX ASS'Y 1 SX-PX554M
28-1 QGKG0113AA ORNAMENT 3
29 QKQGN995AAZK LEFT PLANK 1
29 QKQGN995ABZK LEFT PLANK 1 SX-PX554M
30 QKQGN996AAZK RIGHT PLANK 1
30 QKQGN996ABZK RIGHT PLANK 1 SX-PX554M
31 QAQG033AAK LEFT LEG ASS'Y 1
31 QAQG033ABK LEFT LEG ASS'Y 1 SX-PX554M
31-1 SHRG2130B-K FOOT 2
31-2 XTB4+16A SCREW 4
32 QAQG034AAK RIGHT LEG ASS'Y 1
32 QAQG034ABK RIGHT LEG ASS'Y 1 SX-PX554M
32-1 SHRG2130B-K FOOT 2
32-2 XTB4+16A SCREW 4
33 QMWG4002AA PEDAL ARM 3
34 QMFG1134AA FELT 3
35 QMBG009AA SPRING 3
36 QMFG1133AA FELT 3
37 QKAG0011AA FOOT 1
38 QMFG1135AA FELT 3
39 SGKG980A LABEL 1
40 QTPG1N017A POWER TRANSFORMER 1
EXCEPT P PC, PY
40 QTPG1N022A POWER TRANSFORMER 1
P, PC, PY ONLY
41 QGUG1040AA BUTTON,POWER SW 1
42 QGPG0139AB END COVER PANEL,LEFT 1
43 QGPG0138AB END COVER PANEL,RIGHT 1
44 QMFG1104AA FELT 1
45 QMWG1041AA WHITE KEY(FIRST OCTAVE A 1
46 QMWG1042AA WHITE KEY(B KEY) 8
47 QMWG1043AA WHITE KEY(C KEY) 7
48 QMWG1044AA WHITE KEY(D KEY) 7
49 QMWG1045AA WHITE KEY(E KEY) 7
50 QMWG1046AA WHITE KEY(F KEY) 7
51 QMWG1047AA WHITE KEY(G KEY) 7
52 QMWG1048AA WHITE KEY(A KEY) 7
53 QMWG1049AA WHITE KEY(TOP OCTAVE C KE 1
54 QMWG2006AA BLACK KEY 36
55 QMCG011BA SPRING 88
56 QMWG9027AA HAMMER(BLACK KEY) 8
57 QMWG9027AB HAMMER(BLACK KEY) 14
58 QMWG9027AC HAMMER(BLACK KEY) 7
59 QMWG9027AD HAMMER(BLACK KEY) 7
60 QMWG9025AA HAMMER(WHITE KEY) 12
61 QMWG9025AB HAMMER(WHITE KEY) 19
62 QMWG9025AC HAMMER(WHITE KEY) 11
63 QMWG9025AD HAMMER(WHITE KEY) 10
64 QMGG060AA RUBBER CAP(HAMMER) 88
20
