Technics SX-PX554 - Cabinet Parts Location

100
4
Ref. No. Part No. Part Name & Description
Pcs
Remarks
Z11 EXBV8V103JV
10K × 4
1 MAIN
Z12-31 EXBV8V471JV
470 × 4
20 MAIN
Z32,33 EXBV8V331JV
330K × 4
2 MAIN
Z34-36 EXBS8V471J
470 × 4
3 MAIN
Z37,38 EXBV8V472JV
4.7K × 4
2 MAIN
Z39,40 EXBV8V223JV
22K × 4
2 MAIN
Notes:
*1: Since SW consists of buttons and P.C.B.s, we do not supply it as an individual part (refer to
“
CABINET PARTS LOCATION” on ).
16. CABINET PARTS LOCATION
37
