Technics SX-PX554

Ref. No. Part No. Part Name & Description
Pcs
Remarks
S1 QSPG1010AA POWER SWITCH 1
S1 QSSGT011AA SLIDE SWITCH 1 COM
S1-S3 QSTGT001AA LEVER SWITCH 3 PKB
SP1,2 QASG14P01A
14CM,4
2
SP3,4 QASG65PH03A
6.5CM,8
2
SW1 EVQ21507K PUSH SWITCH 1 CPR
SW1 QSRGT005AA VOLTAGE SELECTOR 1
FJASP
SW2 EVQ21507K PUSH SWITCH 1 CPR
SW9,10 EVQ21507K PUSH SWITCH 2 CPR
SW17 18 EVQ21507K PUSH SWITCH 2 CPR
SW25 26 EVQ21507K PUSH SWITCH 2 CPR
SW33 34 EVQ21507K PUSH SWITCH 2 CPR
SW41 42 EVQ21507K PUSH SWITCH 2 CPR
SW49 EVQ21507K PUSH SWITCH 1 CPR
SW59 60 EVQ21507K PUSH SWITCH 2 CPL
SW65-68 EVQ21507K PUSH SWITCH 4 CPL
SW73-76 EVQ21507K PUSH SWITCH 4 CPL
SW81 82 EVQ21507K PUSH SWITCH 2 CPL
SW84 EVQ21507K PUSH SWITCH 1 CPL
SW89 EVQ21507K PUSH SWITCH 1 CPL
SW1-4 — SWITCH 4 MKB1*1
SW5-16 — SWITCH 12 MKB1*1
SW17-28 — SWITCH 12 MKB1*1
SW29-40 — SWITCH 12 MKB1*1
SW41-52 — SWITCH 12 MKB1 MKB2*1
SW53-64 — SWITCH 12 MKB2*1
SW65-76 — SWITCH 12 MKB2*1
SW77-88 — SWITCH 12 MKB2*1
VR2 QRVG25P01B53 5KÉB,MAIN VOLUME 1 CPL
W1 QEXGRA01005A WIRE 1 HP
W1 QJLG013AA PEDAL CORD 1
W2 QEXGST16060B CONNECTOR WITH WIRE 1
W3 QEXSS05028A CONNECTOR WITH WIRE 1
W4 QEXGSS6030B CONNECTOR WITH WIRE 1
W5 QEXGSS10015A CONNECTOR WITH WIRE 1
W6 QEXGSS07010A CONNECTOR WITH WIRE 1
W7 QEXGSS12010A CONNECTOR WITH WIRE 1
W8 QEXGVH04075F CONNECTOR WITH WIRE 1
W9 QEXGSS16022C CONNECTOR WITH WIRE 1
W10 QEXGVH05055C CONNECTOR WITH WIRE 1
W11 QEXGSS06105A CONNECTOR WITH WIRE 1
W12 QEXGVH03105B CONNECTOR WITH WIRE 1
W13 QEUGQ8H08BCZ CONNECTOR WITH WIRE 1 MKB2
X1 EFOMC4004T5 4MHZ,CERAMIC OSCILLATOR 1 CPL
X1 QSXG2F2400A 24MHZ,CERAMIC OSCILLATOR 1 MAIN
X2 QSXG2FR614DA 614MHZ,CERAMIC OSCILLATOR 1 MAIN
X3 QSXG2F0100DA 1MHZ,CERAMIC OSCILLATOR 1 MAIN
X4 QSXG1A1128A 11.28MHZ,CRYSTAL OSCILLAT 1 MAIN
Z1-Z9 EXBV8V101JV
100 × 4
9 MAIN
36
