Technics SX-PX554

Ref. No. Part No. Part Name & Description
Pcs
Remarks
D60 MA165TA5 DIODE 1 CPL
D61-65 MA165 DIODE 5 MKB1
D65 MA165TA5 DIODE 1 CPL
D66 MA165 DIODE 1 MKB1
D66 MA165TA5 DIODE 1 CPL
D67 MA165 DIODE 1 MKB1
D67 MA165TA5 DIODE 1 CPL
D68 MA165 DIODE 1 MKB1
D68 MA165TA5 DIODE 1 CPL
D69-73 MA165 DIODE 5 MKB1
D73 MA165TA5 DIODE 1 CPL
D74 MA165 DIODE 1 MKB1
D74 MA165TA5 DIODE 1 CPL
D75 MA165 DIODE 1 MKB1
D75 MA165TA5 DIODE 1 CPL
D76 MA165 DIODE 1 MKB1
D76 MA165TA5 DIODE 1 CPL
D77 MA165 DIODE 1 MKB1
D77 MA165TA5 DIODE 1 CPL
D78-81 MA165 DIODE 4 MKB1
D81 MA165TA5 DIODE 1 CPL
D82 MA165 DIODE 1 MKB1
D82 MA165TA5 DIODE 1 CPL
D83,84 MA165 DIODE 2 MKB1
D84 MA165TA5 DIODE 1 CPL
D85-89 MA165 DIODE 5 MKB2
D89 MA165TA5 DIODE 1 CPL
D90-76 MA165 DIODE 87 MKB2
D232-42 LN282RPXVTX2 LED(RED) 11 CPR
D244-46 LN282RPXVTX2 LED(RED) 3 CPR
D256-59 LN282RPXVTX2 LED(RED) 4 CPL
D264-67 LN282RPXVTX2 LED(RED) 4 CPL
D280-83 LN282RPXVTX2 LED(RED) 4 CPL
D288,89 LN282RPXVTX2 LED(RED) 2 CPL
D291 LN282RPXVTX2 LED(RED) 1 CPL
F1 XBA1C63NU100 6.3A,125V 1
FJASP P PC PY ONLY
F1 XBA2C31TB0 T3,15A,250V 1
FJASP EXCEPT P PC PY
F2,F3 XBA2C20TB0 T2A,250V 2
F4 XBA1C25NU100 2.5A,125V 1
FJASP P PC PY ONLY
F4 XBA2C20TB0 T2A,250V 1
FJASP EXCEPT P PC PY
F5 XBA1C25NU100 2.5A,125V 1
FJASP P PC PY ONLY
F5 XBA2C20TB0 T2A,250V 1
FJASP EXCEPT P PC PY
IC1 HD74LS138P 3 TO 8 DECODER 1 MKB1
IC1 KIA7815PI +15V VOLTAGE REGULATOR 1
FJASP
IC1 M37471M2196S 8 BIT MICROCOMPUTER 1 CPL
IC1 TMP95C061BF 16 BIT MICROCOMPUTER 1 MAIN
IC2 D74HC139GSE2 DECODER 1 MAIN
IC2 HD74LS07P 3 TO 8 DECODER 1 CPL
IC2 KIA7915PI -15V VOLTAGE REGULATOR 1
FJASP
IC3 HD74LS07P 3 TO 8 DECODER 1 CPL
IC3 HD74LS138P 3 TO 8 DECODER 1 MKB2
IC3 M5218AL OPERATIONAL AMP 1 FJASP
IC3 M5M34051FPE2 BUS TRANSCEIVER 1 MAIN
28
