AOperating instructions for the machine
C
Ref. DCD01/3078 - TD412_en_C
13/62
Box 2
• Control Unit
Remove the CCU’s protective packing at the last moment. Quickly connect the optical
fiber as soon as the marking head is in position on its mounting bracket (workstation).
Remove the protective plugs only when installing.
Unpack as shown in the following diagram.
Keep the packing in case the machine has to be returned.
Dismantling the system: see page(s) 58
