AIntroduction
A
Ref. DCD01/3078 - TD412_en_C
5/62
2. Identification of the marking equipment
The marking equipment is identified by:
• 1 identification plate on the marking head
• 1 identification plate on the Control Unit
• 1 identification plate on the Laser module
Have the model and serial number of the equipment available when contacting Gravotech.
3. Labels
The various compliance labels are:
Required safety labels
Warranty labels
These labels guarantee the TD412 laser was not opened
or dismantled.
Opening without prior written consent voids warranty.
Focal lens distance indications
This label is placed on the marking head to indicate the distance to the
part.
These values are approximative.
DO NOT OPEN LASER COVER
WARRANTY VOID IF
SEAL IS BROKEN
LENS F(mm)
f 100 115
f 160 195
f 254 350
f 330 430
