AOperating instructions for the machine
C
Ref. DCD01/3078 - TD412_en_C
15/62
3. Technical specifications
 Laser beam
• class 4 (EN60825-1) (class 1 with suitable protection)
• power: 12 W maximum
• minimim pulse duration: 5 ns
• frequency: 5 kHz - 200 kHz
• wave length: 1064 nm
 Power supply
• power supply: 100 - 240 V AC - 50/60 Hz - 400 W (700 W max)
• phases: 1
• fuse: 3.15 A - 230 V / 6.3 A - 115 V
 Environment
• operating temperature: 15
0
C (59
0
F) - 35
0
C (95
0
F)
• storage: 10
0
C (50
0
F) - 40
0
C (104
0
F)
• humidity level: 20 - 80%
 Aiming diode - focusing diode
• power: 1 mW (maximum)
• wave length: 650 nm
• class 2M (EN 60825-1)
4. Physical characteristics
• dimensions (L x w x h):
- Laser module + marking head: 690 mm (27.165 in) x 138.4 mm (5.449 in) x 203 mm (7.992 in) (without optical
fiber)
- Control Unit: 483 mm (19.016 in) x 400 mm (15.748 in) x 229 mm (9.016 in) (with rack-mount bracket)
See: Dimensional drawings
• weight:
- Laser module + marking head: 13 kg (28.66 lb)
- Control Unit: 21 kg (46.297 lb)
• Marking area:
- F100: 65 mm (2.559 in) x 65 mm (2.559 in)
- F160: 110 mm (4.331 in) x 110 mm (4.331 in)
- F254: 180 mm (7.087 in) x 180 mm (7.087 in)
- F330: 240 mm (9.449 in) x 240 mm (9.449 in)
CAUTION: Laser radiation of the aiming diode
Avoid direct eye exposure to diode laser beam.
Do not direct the beam towards other persons, openings or windows.
