AIncidents and resolution of the problems
H
Ref. DCD01/3078 - TD412_en_C
57/62
Imperfect marking
If the finished marking is imperfect:
• Adjust the focus by raising or lowering the Laser in relation to the piece, or vice-
versa.
• Check that the power is not too low for marking.
• Check that the marking speed and the pulse repetition frequency are appropriate
to the materials used.
• Check the electrical connections and the condition of the optical fiber.
• Check that the optical fiber is not curved into a radius of less than 90 mm
(3.543 in).
• Check the focal lens is clean.
No marking
Check if there is the cap for the focal lens’ protection.
If the item is not marked:
• Put the safety key in 1 position.
• Press the "shutter" button (indicator light on).
• Load the marking file.
• Launch the marking cycle.
If the problem persists:
• Restart the machine using the start-up instructions. See: Laser startup
• Check all the connectors.
• Check that the electrical connections "Interlock" and "Stop marking" are properly
closed.
The machine does not
start
If the machine does not start:
• Check that the power cable is connected.
• Check the condition of the fuse.
• Check that the emergency stop is not activated.
