TechnipFMC ALIV-ST-XP User Manual


8.4. AC Digital Output
AccuLoad
External AC Wiring
L1 AC
L1 AC
External DC actuated
device (i.e. Valve)
Figure 23. 
8.5. DC Digital Output
AccuLoad
External DC Wiring
+24 VDC from A4M
TBE4 - 10, 11 or 12
DC Ground from A4M
TBE4 - 13, 14 or 15
External DC actuated
device (i.e. Valve)
DC Output +
DC Output -
Figure 24. 
8.6. DC Digital Input
DC Ground from A4M
TBE4 - 13, 14 or 15
+24 VDC from A4M
TBE4 - 10, 11 or 12
DC Input -
DC Input+
AccuLoad
External DC Wiring
Figure 25. Digital input
     
