4
Front of TV
Rear sight
RF in
LNB 2
input
LNB 1
input
Network port
Mains power
connection
Smartcard
card reader
HDMI
output
USB port
Analogue / digital
audio outputs
S / PDIF out
electr. / optical
CI module
socket
OK
Arrow keys
On / standby
Display USB port
SD / MMC
card reader
Inserting the CONAX / NAGRAVISION (HD+) smartcard:
> Insert the CONAX / NAGRAVISION (HD+) smartcard (gold chip facing
down and to the front as you insert it) and push it in as far as it will go.
Inserting the CI / CI+ module:
> Consult the CI / CI+ module and card manufacturer's instructions.
> Insert the desired Smartcard into the corresponding CI module.
> Now carefully insert the CI module into the slot.
