10
f. After successfully installing the tuner module, continue with section 3.2 (Using an
optional tuner module) or section 4 (Connecting the DVB receiver).
3.2 Inserting the optional tuner module
Your DVB receiver can also be equipped with an additional tuner module:
a. Disconnect the unit from the mains power supply. Please also note section 2.2 (peri-
ods of non-use).
b. Press the securing hooks on the protective cover together and remove the cover.
c. Note the printing on the tuner module to ensure that it turns in the correct position and
insert the tuner module with the contact strip facing forwards into the slot which is now
open.
d. Now slide the tuner module into the unit until you feel slight resistance. Now carefully
push the tuner module further in using slight pressure to connect the tuner with the
unit. If it is not possible to push in the tuner module as the stop using slight pressure,
remove the tuner module and start again from section c.).
e. Now screw in the tuner module using the screws provided.
f. After successfully installing the tuner module, continue with section 4 (Connecting the
DVB receiver).
