9
3 Optional Hardware
Your DVB receiver can also be equipped with optional hardware, such as various tuner
modules and an internal 2.5” hard drive.
3.1 Installing the optional internal hard drive
Your DVB receiver can also be equipped with an internal 2.5” hard drive or SSD for DVR
recording functionality:
a. Disconnect the unit from the mains power supply. Please also note section 2.2 (peri-
ods of non-use).
b. Now press the handle of the hard drive drawer together to release the lock and care
-
fully remove the drawer from the housing.
c. Insert your 2.5” hard drive or SSD in the drawer with the contact strip pointing towards
the open end of the drawer.
d. Now carefully click in the securing hook of the drawer first on one side of the 2.5” disc
drive and then on the other. If this is not possible with light pressure, remove the hard
drive from the drawer and reposition it. Depending on the disk drive being used, the
underside may need to face upwards to allow it to engage.
e. Now slide the drawer into the unit until you feel slight resistance. Now carefully push
the drawer further in using slight pressure to connect the disk drive with the unit. If it is
not possible to push in the drawer as far as the stop using slight pressure or until the
drawer engages, repeat the procedure starting from section b.) and check that the disk
drive is positioned correctly.
