5
Front of unit
Rear of unit
LNB 1
input
LNB 2
input
Loop
out
RF in
Audio outputs
analogue/digital
Tuner slot
Mains power
connection
USB
ports
HDMI
output
SCART
socket
Network
port
S/PDIF
out
Hard drive
drawer
OK
Arrow
keys
On/Stand-by
Display USB port
SD/MMC
card reader
Smartcard
card reader
socket
CI modules
Einlegen der CONAX Smartcard:
> Push the CONAX Smartcard (gold chip face down and aligned in the direc-
tion of insertion) into the Smartcard reader as far as the stop.
Inserting the CI/CI+ modules:
> Please refer to the CI/CI+ module and card manufacturer’s instructions.
> Insert the Smartcard you want into the relevant CI module.
> Now carefully insert the CI module into the slot.
