BIKERACE: Service & Maintenance Manual - rev. 1.1
Page 9.1
9. CONFIGURING THE MACHINE
9.1. MACHINE HW CONFIGURATION
The HW configuration of the machine is set using the 2 banks of dip-switches on the back of the
CPU board, according to the tables below:
9.1.1. MACHINE NO. CONFIGURATION
Using the bank of 4 dip-switches on the back of the CPU board, it is possible to set the machine
number as illustrated below:
Right hand bank
Dip-switch
1 2 3 4
Number
ON OFF OFF ON 1 – MASTER
OFF ON OFF OFF 2
ON ON OFF OFF 3
OFF OFF ON OFF 4
ON OFF ON OFF 5
To be enabled for printing, the machine must be configured with all dip-switches in ON
position.
9.1.2. ALTERNATOR CONFIGURATION
This procedure is applicable starting from SW version 6.0 .
Using the 2 dip-switches of the 2-switch bank on the back of the CPU board, it is possible to set the
type of alternator that is fitted on the machine, as indicated below:
Left-hand bank
Dip-switch
1 2
Alternator
OFF OFF OLD EFEL
ON ON
ON OFF
OFF ON
NEW EFEL
REAL
MAGNETI MARELLI
