Page 2.1
2. TECHNICAL CHARACTERISTICS
2.1. MECHANICAL CHARACTERISTICS
Width 58 cm
Length 140 cm
Height 140 cm
Weight 86 Kg
2.2. ELECTRICAL CHARACTERISTICS
Mains voltage 115 / 230 VAC
Frequency 50 - 60 Hz
Consumption ~ 60 Watt – 0.6 / 0.3 A
Fuses 5x20 3.15 A fast-blow
The mains voltage is set by means of a special jumper on the power supply circuit board.
An incorrect voltage setting can cause irreversible damage to the power supply unit.
Before changing the mains voltage setting, the machine must be turned off and the
mains lead unplugged from the wall output.
2.3. AMBIENT SPECIFICATIONS
Operating from 5° to 35° C
Temperature
Storage from -20 to 55° C
Operating from 30% to 80% non-condensing
Humidity
Storage from 5% to 85% non-condensing
2.4. CONFORMITY TO REGULATIONS
The machine conforms to the following directives:
Europe USA
EMI
EN 60601-1-2
Safety
EN 60601-1
EN 957-1
Directive
73/23/CEE
93/68/CEE
89/336/CEE
UL 2601-1
