18
SYNCHRO ARTIS
B
A
A
A
C
LEVELLING
In order to function correctly, the product must be level.
For the levelling operation, use the two front feet and the central foot.
- Loosen the locknut (B).
- Screw or unscrew the foot (A) until the frame is in a stable position.
- Tighten the locknut (B) for the two front feet. The central foot (C) must
NEVER touch the oor in this phase.
- Unscrew the central foot (C) until it touches the ground.
- Tighten the locknut (B) for the central foot.
