OTHER CONNECTIONS
A - Antenna cable jack
B - Ethernet jack
C - HDMI jack
To reach the jacks, open the panel (D): put a nger in the specic hole and pull.
After connection, close panel (D) putting the cables through the slot.
Use an RF coaxial cable to connect the antenna with an F-type connector for
the product.
The wall socket for the antenna cable must be located in a position where the
plug can be inserted and removed with ease.
