A3RE/FE & BBCV with TM-21’s Electrical System With Stacked Skirt
Mounted Condenser
Evaporator # 1 Circuit Breaker 50 amps
Evaporator # 2 Circuit Breaker 50 amps
Stacked Condenser Circuit Breaker 35 amps
Control System # 1 Circuit Breaker 7 amps
Control System # 2 Circuit Breaker 7 amps
A3RE/FE & BBCV with TM-21’s Electrical System With Roof Top
Condenser Pair
Evaporator # 1 Circuit Breaker 50 amps
Evaporator # 2 Circuit Breaker 50 amps
Roof Top Condenser # 1 Circuit Breaker 25 amps
Roof Top Condenser # 2 Circuit Breaker 25 amps
Control System # 1 Circuit Breaker 7 amps
Control System # 2 Circuit Breaker 7 amps
Micro Bird Electrical System
Evaporator Circuit Breaker 50 amps
Condenser Circuit Breaker 25 amps
Control System Circuit Breaker 7 amps
