TechPlus ComfortAire - Refrigeration Chart

Refrigeration Chart
Normal Evaporator Range Normal Condenser Range
Off Coil Air Temp PSI Outside Air Temp PSI
26 15.69 53 110.20
28 17.04
54 112.10
30 18.43 55 114.10
32 19.87 60 124.30
34 21.35 62 128.50
36 22.88 64 132.90
38 22.47 66 137.30
40 26.10 68 141.90
42 27.79 70 146.50
44 29.52 72 151.30
46 31.32 74 156.10
48 33.17 76 161.10
50 35.07 78 166.10
52 37.03 80 171.30
54 39.05 82 176.60
55 40.09
84 182.00
60 45.48 86 187.50
65 51.27 88 193.10
70 57.47 90 198.90
75 64.10 95 213.70
80 71.19 100 229.40
85 78.75 105 245.80
90 86.80 110 263.00
95 95.40 115 281.10
100 104.40 120 300.10
101 106.30 125 320.00
102 108.20 130 340.80
Range show in Bold
61
1
APPENDIX
