6. Remove the coils lead wire from the holder on the compressor.
7. Remove the three screws that attach the coil to the compressor and
remove the coil.
Clutch Installation
1. Confirm the felt is installed on the front of the cylinder head.
2. Install the coil on the compressor (with the lead wire on top). At this time
confirm the coil’s concave portion is aligned with the felt then tighten the
screws to the proper torque specifications.
Note: Specified Torque: 2.9 to 4.3 ft-lbs.
3. Install the lead wire in the wire holder on the compressor.
