TECNA WELD TESTER TE1700
In the limits mask image shown in the page above, it can be noted that
current and energy limits are active whilst the third limit is not.
As a general rule, the following assumptions are true:
• If the MIN and MAX fields coincide, the welding limits on the
quantity selected are not active.
• Within the mask, it is not possible to select the same quantity
for different welding limits.
Always referring to the image in the previous page, the three buttons
allow you to access the programming page of the first, second and
third welding limit of the selected control mask.
PAGE 29
