INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01
28 GB
RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I –
BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I –
BR1G160I.M” “BR1G200I – BR1G200I.M”
6.6 FIG. GAS VALVE
LEGEND:
A
Pilot burner
F
Electronically controlled gas valve
B
Thermocouple
C
Ignition plug
D
Thermo-pile
BT-S1
Operating thermostat
E
Ignition device
BG3
Heating microswitch
