FLUXMASTER 50 INSTRUCTION MANUAL
2.3.2 Functional Specifications
12
Item Specification
Input Signal Type (SOURCE) input (External 24VDC Input is allowed) (PNP type)
Control Method Sinusoidal wave PWM control
Frequency Range 1 ~ 200Hz*
1
Resolution Setting
Digital: 0.1Hz (1 ~ 99.9Hz); 1Hz (100 ~ 200Hz)
Frequency Analog: .06Hz / 60Hz
Control Keypad Setting Directly setup by ▲ ▼ buttons.
External Signal Setting 0 ~ 10V, 4 ~ 20mA, 0 ~ 20mA
Other Function Frequency upper and lower limit
Carrier Frequency 4 - 16KHz*
2
Accel/Decel Time 0.1 ~ 999 Sec
V/F Pattern 6 Patterns
Torque Control Adjustable Torque boost level (manual torque boost)
2 Programmable Inputs, to be used as multi-speed 1(SP.1) / multi-speed
Control
Multi-Function Input 2(SP.2) *1/ Jog / External emergency stop / External Base Block Command/
Characteristics
Reset Command
Multi-Function Output One output contact available as Fault / Running / At speed signals.
Braking Torque
1P2~101/2P2~201: Approximately 20%
202/203/401/402/403: 20% ~ 100%, built-in braking transistor
Built-In Functions
Decelerate or free run stop, Auto reset,DC braking frequency /
Voltage / Time can be setup by constants.
Display
Three digit 7 segment LED display frequency / functions constants /
fault record /CPU version.
Operating Temperature 14 ~ 104˚F (-10 ~ 40˚C); 14 ~ 122˚F ( -10 ~ 50˚C) without shield sticker
Humidity 0 ~ 95% RH non-condensing.
Vibration Under 1G (9.8m/S
2
)
EMC Specification EN50081-1, EN50081-2, EN50178, EN61800-3 + All
UL UL508C
Overload Protection 150% for 1 minute
Overvoltage DC Bus voltage > 410V(100/200 series); DC Bus voltage > 800V(400 series)
Undervoltage DC Bus voltage < 200V(100/200 series); DC Bus voltage < 400V(400 series)
Protection Momentary
Power-loss 0 ~ 2 sec: AC drive can be restarted with Speed Search.
Function Power Loss
Stall Prevention During Acceleration / Deceleration/ Constant speed
Output Short-circuit Electronic circuit protection
Ground Fault Electronic circuit protection
Other Protection Heatsink overheat protection,Current limit
Installation Direct installation or DIN rail (Option).
Note: *1: CPU version v1.9 and above.
*2: Carrier Frequency Range: CPU Version v1.6 is 4 ~ 8kHz.
CPU Version v1.9 and above are 4 ~ 16kHz.
To Next Page
