FLUXMASTER 50 INSTRUCTION MANUAL
To fully employ all functions of this AC drive, and to ensure the safety for its users,please read through this operations manual in
detail. Should you have any further questions, please feel free to contact your local distributor or regional sales representative.
1. SAFETY PRECAUTION
The AC Drive is a power electronic device.For safety reasons,please read carefully those paragraphs with "WARNING" or
"CAUTION" symbols.They are important safety precautions to be aware of while transporting,installing,operating,or examining
the AC drive. Please follow these precautions to ensure your safety.
WARNING Personal injury may result from improper operation.
CAUTION The AC Drive or mechanical system may be damaged by improper operation.
WARNING
❙ Do not touch the PCB or components on the PCB right after turning off power and before the charging indicator goes off.
❙ Do not attempt to wire circuits while power is on.Do not attempt to examine the components and signals on the PCB
while the AC drive is operating.
❙ Do not attempt to disassemble or modify internal circuitry, wiring,or components of the AC drive.
❙ The grounding terminal of the AC drive must be grounded properly with 200V class type III standard.
❙ This is a product of the restricted sales distribution class according to EN61800-3.
❙ This product may cause radio interference.The user may be required to take adequate measures for RFI protection.
CAUTION
❙ Do not attempt to perform dielectric strength tests on internal components of the AC Drive.There are sensitive
semiconductor-devices vulnerable to high voltages.
❙ Do not connect the output terminals:T1 (U),T2 (V), and T3 (W) to AC power input.
❙ The CMOS IC on the primary PCB of the AC drive is vulnerable to static electrical charges. Do not touch the primary PCB
of the AC drive.
