❙ Ground circuit must not be formed when grounding several AC drives together.
(D) Wire specification. Apply appropriate wire with correct diameter for primary power circuitry and control circuitry in
compliance with NEC or other applicable codes.
2.4 Wiring Diagram
Wire Terminations to the AC drive must be made with either UL listed field wiring lugs or UL listed crimp type ring terminals.
*Note: Only for 230V 2,3HP and 460V 1-3HP models.
To Next Page
