28 Challenger Series Installation and Quick Programming Manual
This manual describes the Challenger programming that you may need for basic
system setup. Refer also to:
• Challenger Series Programming Manual for details of Challenger system
programming via the Install menu.
• Challenger Series Administrators Manual for details of Challenger
programming and operation via the User menu.
User menu options
As part of the basic system setup you may need to use the following User menu
options:
• Option 7, Service Menu
• Option 12, Test Input
• Option 14, Program Users
• Option 15, Program Time & Date
• Option 20, Door & Floor Groups
• Option 21, Holidays
To access the User menu:
Use the following steps to access the Challenger User menu when the Code
prompt is displayed on the bottom line of the RAS.
1. Press [MENU*].
To Access Menu Enter Code
Code:
2. Enter 4346 (default Installer code), and then press [ENTER].
“0”-Exit “ENTER” -Down “*” -Up
0-Exit, Menu:
3. You can now select the programming option you need from the User menu.
To access the Install menu, enter 19 (Install menu option number), and then
press [ENTER].
Install Menu
0-Exit, Menu:
You can now select the programming option you need from the Install menu (see
Table 3 on page 29).
Install menu options
The Install menu options and the default settings of particular importance to
installers are listed in Table 3 on page 29.
