TECOM Challenger10 TS1016 - Product Overview; Product Contents

Challenger Series Installation and Quick Programming Manual 1
Product overview
Challenger is a scalable intrusion detection and access control system.
Challenger panels use one, and optionally a second, RS-485 data bus (LAN) to
provide continuous polling of remote arming stations (RAS) and data gathering
panels (DGP). These devices extend the system’s intrusion detection and access
control functions.
Refer to the Challenger Series Programming Manual for details.
Product contents
Table 1 below lists the items that are shipped with Challenger control panels.
Table 1: Challenger panel shipping list
Quantity
Item
1
Metal enclosure (with four spring standoffs fitted)
1
Challenger panel board
1
604 to RJ12 lead line, 1.5 m (not applicable to ChallengerLE)
1
Challenger Series Administrators Manual
1
Challenger Series User Manual
1
Challenger Series Installation and Quick Programming Manual
1
16 Volt AC plug pack (applies to TS1016, TS1016SE, and TS1016LE)
1
240 VAC mains transformer, 2A, with mains power cord (applies to TS1016T)
1
240 VAC terminal block with fuse (applies to TS1016T)
1
Tamper switch
1
Tamper switch metal bracket
1
Ring terminal
5
M3 x 14 pan head screws
15
3-way plug-on screw terminal connectors (13 for TS1016LE)
10
2-way plug-on screw terminal connectors (3 for TS1016LE)
1
Red battery lead with QC terminal
1
Black battery lead with QC terminal
1
1K 1/4 watt resistor
40
10K 1/4 watt resistors (20 for TS1016LE)
Inspect the package and contents for visible damage. If any components are
damaged or missing, do not use the unit; contact the supplier immediately.
