30 Challenger Series Installation and Quick Programming Manual
Install menu option
Description
7. System Options
Program the system options if the default values are not suitable.
The default values for system options are:
• Film Low is set to 800
• Film Out is set to 1100
• Input tamper monitoring is selected
• Display one input at a time is selected
• User name file is selected
• EOL resistor is 10K
• Time zone is set to None
• Area search time zone is not set
8. Auto Reset
Program the Challenger to automatically reset alarms.
9. Communications
Program the communications devices and paths for reporting to a
remote monitoring company, connecting to management software
computers, and so on.
10.
Reserved This option is not currently used.
11. Version
Display the system’s device types and firmware version numbers.
12. Lamp Test
Toggle the on/off state of all RAS LEDs in the system so that they
may be checked.
13. Time Zones
Define time slots (hard time zones) in which certain events can take
place.
14. Defaults
Reset the panel to default settings.
15. User Category
User categories provide timing for areas that are configured for timed
disarming or for delayed arming via vault programming.
Note: Vault programming is not applicable to ChallengerLE.
16. Map Relays
Link relays (outputs) to event flags and/or time zones.
The default values for relay mapping are:
• Relay 2 (panel strobe output) is mapped to event flag 2.
• Relays 16, 32, 48, 64, and so on (panel siren driver) are mapped
to event flag 1. The sixteenth relay assigned to each DGP (DGP
siren drivers) is mapped to event flag 1.
17. Arm/Disarm via Tz
Define arm/disarm timer programs. Areas being armed or disarmed
automatically (by time zone) do not require any user action.
18. Vaults
Define areas that, when armed, will automatically arm other areas
after a specified time.
Note: Vault programming is not applicable to ChallengerLE.
19. Area Linking
Define a commo
n area that is armed only when the last shared area is
armed.
21. Input Shunts
Define shunt timers to inhibit inputs from generating alarms during a
specified interval.
22. TZ to Follow Relays
Define soft time zones. Time zones 26 to 41 can be programmed to
be valid when a relay is active and invalid at other times.
23. Poll Errors
Display
the number of errors detected in communications between the
control panel and the devices connected to the control panel.
