TECOM TS1066 - Lock Types

ChallengerPlus
LAN
Address
Polled as
4 Doors
Mode
8 Doors
Mode
LAN 2
1
DGP 17
81 to 84
81-88
LAN 2
2
DGP 18
85 to 88
85-92
LAN 2
3
DGP 19
89 to 92
89-96
LAN 2
4
DGP 20
93 to 96
93-100
LAN 2
5
DGP 21
97 to 100
97-104
LAN 2
6
DGP 22
101 to 104
101-108
LAN 2
7
DGP 23
105 to 108
105-112
LAN 2
8
DGP 24
109 to 112
109-116
LAN 2
9
DGP 25
113 to 116
113-120
LAN 2
10
DGP 26
117 to 120
117-124
LAN 2
11
DGP 27
121 to 124
121-128
LAN 2
12
DGP 28
125 to 128
-
When an operator connects CTPlus to a NAC, doors are automatically created:
eight doors if the NAC is in IP Direct mode, eight doors if the NAC is in IP
Extended or Classic mode with 8 Door Mode or four doors if the NAC is in IP
Extended or Classic mode with 4 Door Mode.
Each door controlled by the NAC can have two door inputs, an egress input, two
lock relays, a DOTL (Door Open Too Long) relay, a forced door relay, a warning
relay, and six assigned readers in any combination of IN and OUT readers.
Each door has various options for access, shunting, egress, and anti-passback.
There are also options for alarm control if the NAC is connected to a
ChallengerPlus panel.
Doors are programmed on the Doors/Lifts form in CTPlus. See the
“Programming doors” section on page 59.
Lock types
To support more complex door operation than the V8 Four-Door Controller, the
Network Access Controller introduces new lock types, with associated inputs,
relays and timers.
The new lock types are:
 Strike
 Maglock
There are two inputs for each door, and two lock relays for each door:
 Door input 1 – Connected to the door to indicate if the door is open or
closed. This is usually the reed switch.
 Door input 2 – Connected to the lock monitor on Strike and Maglock
locks.
