The RAS on the system LAN that is selected for arm control must also have the
“Toggle keyboard control” option enabled. See the ChallengerPlus Programming
Manual for information on the “Toggle keyboard control” option.
Enter a RAS number or click the Browse button to select a RAS.
IN alarm control levels
This field shows a list of alarm control levels for the door’s IN readers, as
configured on the Readers tab for the door. Alarm control levels are defined on
the DGP form’s Alarm Control Levels.
Click the Assign button to open a dialog to assign alarm control levels to the
door’s IN readers. In the dialog, move the required alarm control levels from the
Available alarm control levels list to the Assigned alarm control levels list
using the button. Alarm control levels can be removed from the Assigned
alarm control levels list using the button. Click the OK button when
finished.
Click the Remove button to remove the selected alarm control level from the
IN alarm levels list.
OUT alarm control levels
This field shows a list of alarm control levels for the door’s OUT readers, as
configured on the Readers tab for the door. Alarm control levels are defined on
the DGP form’s Alarm Control Levels.
Click the Assign button to open a dialog to assign alarm control levels to the
door’s OUT readers. In the dialog, move the required alarm control levels from
the Available alarm control levels list to the Assigned alarm control levels list
using the button. Alarm control levels can be removed from the Assigned
alarm control levels list using the button. Click the OK button when
finished.
Click the Remove button to remove the selected alarm control level from the
OUT alarm levels list.
Programming input and relay mapping
See the “Input and relay mapping” section on page 21 for information on input
and relay mapping.
Note: Input and relay mapping does not apply to the NAC in IP Direct mode.
