Door 1 device
Location
Address
Device
Figure
reference
Lock relay 2
DGP
2
1
(E)
DOTL relay
Onboard
-
4
(F)
Forced door relay
Onboard
-
5
(G)
Warning relay
DGP
17
6
(H)
Assigned reader 1
RAS
1
1
(I)
Assigned reader 2
DGP
1
1
(J)
Assigned reader 3
DGP
1
2
(K)
Assigned reader 4
-
-
-
-
Assigned reader 5
-
-
-
-
Assigned reader 6
-
-
-
-
Figure 4: Device locations example
