To add a new user to a NAC, follow these steps:
1. Click the Users button on the User access ribbon tab to open the
Users form.
2. On the Users form, click the New button in the toolbar to add a new
user record.
3. Enter the required information on the User tab.
4. On the Access tab, ensure that the Door groups field has a door group
entry that has NAC doors. Click the Assign button to open a door
group selection dialog. Select a door group and click the OK button.
5. Click the Save button in the toolbar to save the user record.
6. On the Cards tab, click the New button to add a new card. In the Cards
dialog, ensure the Panel field is set to the relevant NAC or ChallengerPlus
panel, and enter the card data and PIN as required. Click the OK button
when finished.
7. Click the Save button in the toolbar to save the user record.
Refer to the ChallengerPlus Programming Manual for more information on users.
Refer to the CTPlus Operators Manual or CTPlus online help for more
information on the Users form.
Note: A NAC in Classic mode is limited to 48 bits of card data. A NAC in IP
Direct or IP Extended mode supports up to 128 bits of card data. However, in IP
Extended mode, cards with more than 48 bits of card data cannot be used for
alarm control functionality.
