Direct mode
In IP Direct mode, the NAC appears as a distinct NAC panel connection. For
example:
The NAC also appears as a DGP under the DGP category (DGP number 16)
of the NAC panel connection. The NAC’s assigned RASs and DGPs appear as
sub-devices under the NAC’s DGP node.
The NAC’s doors appear as doors under the Door category of the NAC panel
connection.
IP Extended mode
In IP Extended mode, the NAC appears as a distinct NAC panel connection.
For example:
