Betriebsanleitung/Operating manual
F2301/F23C1/F23S1
www.tecsis.de BD_BE_912 c 27
1.6 Operating location conditions
The load cells must be protected from mechanical and electrical
damage.
1.7 Maintenance
The load cells in the F2301/F23C1/F23S1 model series are mainte-
nance-free. During welding work the load cell must be bypassed with a
copper wire (min. 50 mm
2
) so that welding current does not flow through
the load cell and weld the force introduction points.
1.8 Accident prevention
!
Although the specified nominal force in the destruction range
is a multiple of the measuring range limit, the relevant accident
prevention regulations of the employer’s liability insurance
association must be taken into consideration.
2 Scope of delivery
Tension/compression load cell, operating manual
3 Deployment areas and usage instructions
The load cells are intended for measuring static and dynamic tension
and / or compression force. Because of their extremely small dimen-
sions, the load cells can also be used in situations where little space
is available. The load cells are suitable for harsh environmental condi-
tions and tough operational demands. They are maintenance-free and
can also be installed in locations that are difficult to access. The wide
range of output signals allows tecsis load cells to be adapted to many
difference usage conditions. As precision measuring devices, the load
cells must be handled with care during transportation and assembly.
Shocks (e.g. colliding with a hard surface) can also cause unexpected
overloading during measuring operation, causing permanent damage.
The limits for the permitted mechanical, thermal and electrical
loads are listed in the “technical data”. These must be complied
with.
