Betriebsanleitung/Operating manual
F2301/F23C1/F23S1
38 BD_BE_912 c www.tecsis.de
8.1 Dimensions
Nom.
force
A
B
D
E
F
G
H
J
K1
K2
K3
L
M
∅N-
0.1
Bowl
R
M
A
(Nm)
Nominal
deflection
1,2,3,5 kN
25.2
22
24
23
4.3
1.5
6
59
43
62
66
70
M12
9.5
60
60
< 0.5
10 kN
25.2
22
31
23
4.3
1.5
6
59
43
62
66
77
M12
9.5
80
60
< 0.5
20 kN
25.2
26
33
34
3.8
2
10
59
43
62
66
101
M20x1.5
17
100
300
< 0.1
30 kN
27.5
27.5
40
34
3.8
2
10
61.5
44
63
67
108
M20x1.5
17
120
300
< 0.1
All dimensions in mm
Version
1
- 30 kN
Counter nut MA see table
