9 Accessories
Articulated heads
Nom.
force
H
T min.
srew in depth
1, 2,3,5 kN
148±3
9.5
10 kN
155±3
9.5
20 kN
219±4
16
30 kN
226±4
16
50 kN
276±4
19.5
100 kN
405±7
31
All dimensions in mm
Nom.
force
in kN
Weight
in kg
A
B
∅D1
∅D2
F
G
GL
∅K
L
M
SW
0…10
0.115
32
16
12 H7
15.4
50
M12
22
22
66
12
19
20…30
0.415
50
25
20 H7
24.3
77
M20x1.5
34
34
102
18
32
50
0.750
60
31
25 H7
29.6
94
M24x2
42
42
124
22
36
100
2
92
28
40-0.012
45
142
M39x3
65
65
188
23
55
All dimensions in mm
Swivel heads acc. DIN ISO 12240-4,
∅D1= 12 to 25 dimension column K
∅D2= 40 to 80 dimension column E
