8 Technical data
Symbol
Unit
Model series
F2301
F23S1
Measurement range
Rated force
F
nom
kN
> 1 kN
Accuracy and stability
Relative linearity error
1)
d
lin
x%F
nom
± 0.2
Relative reversibility error
v
x%F
nom
< 0.1
Relative creep
-
x%F
nom
0.1
Temperature effect on zero signal
TK
0
%/10 K
0.2
Temperature effect on characteristic value
TK
C
%/10 K
0.2
Mechanical characteristics
Force limit
F
L
x%F
nom
150
Breaking force
F
B
x%F
nom
300
Permissible oscillation stress
F
rb
x%F
nom
± 50
Rated displacement s
nom
mm
< 10 kN: < 0.02
< 100 kN: < 0.2
Material of measuring spring
corrosion resistant stainless steel
ultrasonic tested 3.1 material / (optionally 3.2)
Temperature ranges
Rated temperature range
B
T, nom
°C
-20…80
Operating temperature range
B
T, G
°C
-30…80 (optional -40…80)
-30…80
Storage temperature range
B
T, S
°C
-40…85
Electrical characteristics
mA
(4…)20, 2-wire,
(4…)20, 3-wire,
2 x (4…)20 redundant
Redundant opposing
4…20 mA/ 20…4 mA acc. the
requirements for functional
safety acc. Machinery Directive
2006/42/EG
V
(0…)10, 3-wire,
2 x (0…)10 redundant
CANopen
®
Configuration of device
address and baud rate
Sync/Async, Node/Lifeguarding,
Heartbeat;
Zero point and full scale
up to ±10% by entries into object
directory
2)
Current consumption mA
Current output 4 … 20 mA
2-wire: signal current
Current output 4 … 20 mA
3-wire: < 8 mA
Voltage output: < 8 mA,
CANopen
®
: <1W
Current output
4 … 20 mA: signal current
Supply voltage VDC
10…30 for current output,
14…30 for voltage output,
12…30 for CANopen
®
10…30 for current output
Burden Ohm
≤ (UB–10 V)/0,024 A for current out-
put
> 10 kΩ for voltage output
≤ (UB–10 V)/0,020 A
(channel 1) for current output
≤ (UB–7 V)/0,020 A
(channel 2) for current output
Responce time
ms
≤ 2 (within 10% up to 90% F
nom
)
3)
General data
Protection (acc. to EN 60529/IEC 529)
IP67 (optional IP69k)
IP67
Vibration resistance
(acc. to DIN EN 60068-2-6)
20 g, 100 h, 50...150 Hz
Electrical protection
Reverse voltage, overvoltage and short-circuit protection
Emission
DIN EN 55011
Immunity
acc. to DIN EN 61326-1/DIN EN 61326-2-3
(optional EMC ruggedized version)
Electrical connection
Circular connector M 12x1, 4-pin,
CANopen
®
5-pin
2-circular connector
M 12x1, 4-pin
Options
Certificates, Strength tests,
3D-CAD data (STEP, IGES) on request
1)
Relative linearity error is specified acc. to VDI/VDE/DKD 2638 chapter 3.3.6 b.
2)
Protocol acc. CiA DS-301 V.402. Device profile DS-404 V. 1.2.
3)
Other response times are available on request.
