Tecsun PL-380 User Manual

After alarm was activated with buzzer or radio broadcasting,
press & release [LIGHT / SNOOZE] with a "B" sound. Then
the radio would be turned off temporary, it will start to alarm
again 5 minutes later.
For the LCD backlight function, short press the [LIGHT]
button to illuminates the LCD for 3 seconds. Long press it
for permanently illumination. Press again the [LIGHT/
SNOOZE] button to turn off the light.
SNOOZE / LIGHT FUNCTION
16
When the unit is alarmed by radio, press the [POWER]
button twice to turn off the alarm.
When the unit is alarmed by buzzer (BB sound), simply
press the [POWER] button once to turn off the alarm.
TURN OFF THE ALARM
With radio OFF: Short press the [DISPLAY] button to view
on Temperature, Alarm time.
With radio ON: Short press the [DISPLAY] button to view on
Alarm time, Temperature, Local time, signal strength/ SNR.
DISPLAY MODE
Long press the [ ] button with " " symbol appears in
the display to lock up all keys / buttons. Long press it again
with the symbol disappears to unlock the keys/buttons.
KEY LOCK FUNCTION

Tecsun PL-380 Specifications

Frequency Range

FM frequency range	87~108 MHz
Russia FM frequency range	64~108 MHz
Japan FM frequency range	76~108 MHz
Eu, USA FM frequency range	87.5~108 MHz
MW frequency range	522~1620 kHz
USA MW frequency range	520~1710 kHz
LW frequency range	153~513 kHz
SW frequency range	2300~21950 kHz

Sensitivity

FM sensitivity	Less than 3μV
MW sensitivity	Less than 1mV/m
LW sensitivity	Less than 10mV/m
SW sensitivity	Less than 20μV

Selectivity

FM selectivity	＞60 dB
MW selectivity	＞60 dB
LW selectivity	＞60 dB

Power

Output power	350 mW
Battery type	UM3 or AA X 3
USB power	5V DC

Audio

Speaker specification	φ50mm, 500mW/16 Ohm
Earphone jack specification	φ3.5mm, 8~32 Ohm, Stereo type
FM Stereo crosstalk	Less than 35 dB

Weight and Dimensions

Dimensions	Approx. 135(W) X 86(H) X 26(D) mm
Weight	200g (Batteries not included)
Memory	550
