Tecsun PL-380 User Manual

4
LCD DISPLAY
Battery consumption indicator /
Charging indicator
1
2
Sleep timer indicator
3
Alarm on/off indicator
" " alarm on by radio
" " alarm on by buzzer
6
Signal indicators
dBu: signal strength unit
dB : Signal to Noise Ratio
(S/N) unit
7
8
SW meter band indicator
9
ETM indicator
4
Temperature (Temp.)
5
AM, PM indicator for 12-hour
format clock
Tuning speed:
" " Slow Tuning
" " Fast Tuning
10
11
kHz: frequency unit for MW,
LW & SW
MHz: frequency unit for FM
15
Key-lock indicator
Digital number display (4 Digits)
With radio off: world time, alarm
time, temperature
With radio on: word time, signal
strength / SNR, alarm time,
temperature, local time, memory
address, meter band.
12
14
Digital number display
With radio off: local time
With radio on: frequency display,
band display
FM stereo status indicator
16
Band indicator
17
Alarm time indicator
Preset memory address
13
Rechargeable batteries indicator
18
SLEEP
1
2 4 6
7
8
18
3
9
5
11
15 14
13
16
10
17
12

Tecsun PL-380 Specifications

Frequency Range

FM frequency range	87~108 MHz
Russia FM frequency range	64~108 MHz
Japan FM frequency range	76~108 MHz
Eu, USA FM frequency range	87.5~108 MHz
MW frequency range	522~1620 kHz
USA MW frequency range	520~1710 kHz
LW frequency range	153~513 kHz
SW frequency range	2300~21950 kHz

Sensitivity

FM sensitivity	Less than 3μV
MW sensitivity	Less than 1mV/m
LW sensitivity	Less than 10mV/m
SW sensitivity	Less than 20μV

Selectivity

FM selectivity	＞60 dB
MW selectivity	＞60 dB
LW selectivity	＞60 dB

Power

Output power	350 mW
Battery type	UM3 or AA X 3
USB power	5V DC

Audio

Speaker specification	φ50mm, 500mW/16 Ohm
Earphone jack specification	φ3.5mm, 8~32 Ohm, Stereo type
FM Stereo crosstalk	Less than 35 dB

Weight and Dimensions

Dimensions	Approx. 135(W) X 86(H) X 26(D) mm
Weight	200g (Batteries not included)
Memory	550
