Tecsun PL-380 User Manual

23
TROUBLE SHOOTING
QUESTIONS ANSWERS SOLUTIONS
Can not turn on
the radio.
Radio goes off
when you are
listening.
Can not store
some stations
using ATS
Some station
store with noise
using ATS.
Only limited FM
stations can be
received in Japan.
Received very
poor AM in USA.
-No power with the
batteries.
-Didn't install the
batteries properly.
-Power button is
locked.
-No power with the
batteries.
-Sleep timer is
activated.
-Frequency of
stations are too
weak.
-There are
interference near
by your area.
-FM frequency is
76~90MHz for
Japan.
-USA is using
10kHz step for AM.
-Replace the new
batteries.
-According to "+" or
"-" sign to install
the batteries again.
-Press [ ] button
to unlocked.
-Replace the
batteries.
-Turn on the radio
again.
-Search the station
manually.
- Low down the
antenna or move
to other location
and try again.
-Turn the radio off
and long press on
the [FM SET]
button，short press
[FM SET] button
again to select
76~108MHz.
-Turn off the radio
press the [9/10kHz]
button to select
10kHz.

Tecsun PL-380 Specifications

Frequency Range

FM frequency range	87~108 MHz
Russia FM frequency range	64~108 MHz
Japan FM frequency range	76~108 MHz
Eu, USA FM frequency range	87.5~108 MHz
MW frequency range	522~1620 kHz
USA MW frequency range	520~1710 kHz
LW frequency range	153~513 kHz
SW frequency range	2300~21950 kHz

Sensitivity

FM sensitivity	Less than 3μV
MW sensitivity	Less than 1mV/m
LW sensitivity	Less than 10mV/m
SW sensitivity	Less than 20μV

Selectivity

FM selectivity	＞60 dB
MW selectivity	＞60 dB
LW selectivity	＞60 dB

Power

Output power	350 mW
Battery type	UM3 or AA X 3
USB power	5V DC

Audio

Speaker specification	φ50mm, 500mW/16 Ohm
Earphone jack specification	φ3.5mm, 8~32 Ohm, Stereo type
FM Stereo crosstalk	Less than 35 dB

Weight and Dimensions

Dimensions	Approx. 135(W) X 86(H) X 26(D) mm
Weight	200g (Batteries not included)
Memory	550
