Tecsun PL-380 User Manual

17
While listening to FM station via stereo earphones, short
press the [FM.ST] button with " " appears over the left
side of the frequency in the display to activate the STEREO
mode once it receives the FM stereo station.
FM ST. (FM STEREO) BUTTON
Short press the [AM BW] button to choose 6, 4, 3, 2, 1 kHz
AM IF bandwidth. This may help to reduce interference on
some frequencies. Using WIDE usually results in better
audio fidelity, while using narrow limits the audio fidelity is
somewhat dull in sound. You can use it in MW, LW and SW
band.
AM BW (BANDWIDTH) BUTTON

Tecsun PL-380 Specifications

Frequency Range

FM frequency range	87~108 MHz
Russia FM frequency range	64~108 MHz
Japan FM frequency range	76~108 MHz
Eu, USA FM frequency range	87.5~108 MHz
MW frequency range	522~1620 kHz
USA MW frequency range	520~1710 kHz
LW frequency range	153~513 kHz
SW frequency range	2300~21950 kHz

Sensitivity

FM sensitivity	Less than 3μV
MW sensitivity	Less than 1mV/m
LW sensitivity	Less than 10mV/m
SW sensitivity	Less than 20μV

Selectivity

FM selectivity	＞60 dB
MW selectivity	＞60 dB
LW selectivity	＞60 dB

Power

Output power	350 mW
Battery type	UM3 or AA X 3
USB power	5V DC

Audio

Speaker specification	φ50mm, 500mW/16 Ohm
Earphone jack specification	φ3.5mm, 8~32 Ohm, Stereo type
FM Stereo crosstalk	Less than 35 dB

Weight and Dimensions

Dimensions	Approx. 135(W) X 86(H) X 26(D) mm
Weight	200g (Batteries not included)
Memory	550
