Tecsun PL-380 User Manual

USING THE INTELLIGENT CHARGING FUNCTION
21
Connect USB 5V to external
power sources
With radio off, install 3 x UM3 (AA) rechargeable batteries
and then press & hold the [ ] key with " " &
" " displays to activate the built in charging function.
1. Use any 5V external adaptor with USB plug to
connect this radio, the symbol " " will advance from
the bottom to top during power charging. It stops when
batteries are fully charged.
2. You can also use any USB cable to connect the radio
with your PC for charging.
Notes for charging power:
1. Insisting to use up all power of rechargeable batteries
before charging again, this could extend the life time of
battery and keeping them in good conditions.
2. 3 pcs of batteries to be used as a group and don't
separate them to other usage. Also don't mix to use
batteries with different power capacity.
Caution: Don't charge on any non-rechargeable batteries in
the radio, this will cause a hazard or damage to your radio.
DC-IN 5V

Tecsun PL-380 Specifications

Frequency Range

FM frequency range	87~108 MHz
Russia FM frequency range	64~108 MHz
Japan FM frequency range	76~108 MHz
Eu, USA FM frequency range	87.5~108 MHz
MW frequency range	522~1620 kHz
USA MW frequency range	520~1710 kHz
LW frequency range	153~513 kHz
SW frequency range	2300~21950 kHz

Sensitivity

FM sensitivity	Less than 3μV
MW sensitivity	Less than 1mV/m
LW sensitivity	Less than 10mV/m
SW sensitivity	Less than 20μV

Selectivity

FM selectivity	＞60 dB
MW selectivity	＞60 dB
LW selectivity	＞60 dB

Power

Output power	350 mW
Battery type	UM3 or AA X 3
USB power	5V DC

Audio

Speaker specification	φ50mm, 500mW/16 Ohm
Earphone jack specification	φ3.5mm, 8~32 Ohm, Stereo type
FM Stereo crosstalk	Less than 35 dB

Weight and Dimensions

Dimensions	Approx. 135(W) X 86(H) X 26(D) mm
Weight	200g (Batteries not included)
Memory	550
