Tecsun PL-380 User Manual

Back stand
22
Multifunctional tuning knob
21
20
FM & SW telescopic antenna
USB 5V DC-IN jack
19
18
Earphone jack
ALARM On/Off & Setting
17
TIME Setting
16
15
LOCK button
VF (View Frequency) & SCAN button (Frequency)
12
VM (View Memory) & Scan button (Memory)
11
AM / BW button (AM IF bandwidth selector)
10
9
Memory button (Storing radio stations) / Batteries type selector
8
0-9 Numeric keys
7
ENTER / DEL ETE button
SW/ ATS button (SW meter band selector & Auto Tuning Storage)
6
MW / LW button ( MW / LW band selector & Auto Tuning Storage)
5
4
FM / ATS button (FM band selector and Auto Tuning Storage)
FM ST. button
3
2
Display button
1
Power on/off
14
LIGHT / SNOOZE
ETM (Easy Tuning Mode) button
13
3
Volume knob
23
Battery compartment
24

Tecsun PL-380 Specifications

Frequency Range

FM frequency range	87~108 MHz
Russia FM frequency range	64~108 MHz
Japan FM frequency range	76~108 MHz
Eu, USA FM frequency range	87.5~108 MHz
MW frequency range	522~1620 kHz
USA MW frequency range	520~1710 kHz
LW frequency range	153~513 kHz
SW frequency range	2300~21950 kHz

Sensitivity

FM sensitivity	Less than 3μV
MW sensitivity	Less than 1mV/m
LW sensitivity	Less than 10mV/m
SW sensitivity	Less than 20μV

Selectivity

FM selectivity	＞60 dB
MW selectivity	＞60 dB
LW selectivity	＞60 dB

Power

Output power	350 mW
Battery type	UM3 or AA X 3
USB power	5V DC

Audio

Speaker specification	φ50mm, 500mW/16 Ohm
Earphone jack specification	φ3.5mm, 8~32 Ohm, Stereo type
FM Stereo crosstalk	Less than 35 dB

Weight and Dimensions

Dimensions	Approx. 135(W) X 86(H) X 26(D) mm
Weight	200g (Batteries not included)
Memory	550
