Tecsun PL-380 - PL-380 Functional Block Diagram

PL-380
Functional Block Diagram
PL-380 is using DSP si4734 Microchips (from Silicon Labs in
USA) to digitalize the analog AM/FM broadcasting signal base
on the modern software technology and radio principles. It can
highly improve on radio's sensitivity, selectivity, S/N ratio and
anti-interference.
AMPLIFIERCONTROLLER
CONTROL
INTERFACE
SW LPF
FM ANT
MW/LW
ANT
PL-380
Functional Block Diagram
