Digital linearity of sensor signal
Protection treatment of the electronic part
DISPLAY AND DATA MANAGEMENT
2 x 13 mm displays with 3 digits to display temperatures, messages and channels
3 LEDs to display the state of the alarms of the selected channel (ALARM-TRIP-FAULT)
4 leds selection of display mode (SCAN-AUTO-MAN-T-MAX)
2 LEDs to display the state of FAN1 and FAN2
Temperature control from 0°C to 240°C (*)
2 alarm thresholds for channels 1-2-3 (**)
2 alarm channels for channel 4 (**)
2 ON-OFF thresholds for FAN 1 and FAN 2
Sensor diagnostics (Fcc-Foc-Fcd)
Data memory diagnostics (Ech)
Access to programming through front keyboard
Automatic exit from programming, display and and test after 1 minute's inactivity
Incorrect programming warning
Selection between channels automatic scanning, hottest channel or manual scanning
Storage of maximum temperatures reached by channels and alarm status
Front key to reset the alarms
WEB SERVER Wi-Fi Function
Synchronization with SERVER NTP (Network Time Protocol) in STATION mode
(*) On demand, available version from -40°C to 200°C with alarm temperature management range from 0°C to 200°C
(**) 4 CH channels with independent programming are available on request, see notes NT935-4 WS.
