ONNECTIONS
:
O
NE
POWER4-HUB
75VDC Bus Input/
Passthrough
75VDC Bus Out (x4)
24VDC
Aux. Supply
IPC-5 75VDC
Bus Supply
ClearPath-SC Motors
AC Source
110/220VAC
75VDC
Bus Out
Power Hub
Single POWER4-HUB System
