Teknic ClearPath-SCSK Series User Manual

C LEAR P ATH -SC U SER M ANUAL R EV . 1.36 89
T
EKNIC , I NC . T EL . (585) 784-7454
A PPENDIX B: M ECHANICAL I NDEX
M OUNTING D IMENSIONS : C LEAR P ATH -SC NEMA 34
31.75 1.250
[L
2.54]
L
.100
2.03
0.080
[31.75 0.020]
1.250 .008
12.708 12.675
0.5003 0.4990
20
0.787
12.7
0.5
44.45
1.75
5
0.197
5
0.197
Recommended clearance for USB cable
108.94 ±0.76 4.289 ±0.030
60.10 ±0.76
2.366 ±0.030
86.87 ±0.76
3.420 ±0.030
73.03
-
0 0.051
2.875
-
0.000 0.002
0.220 5.60
THRU
98.43
3.875
90°
45°
50
1.969
6.70
0.264
50
1.969
USB Access
Model Number
“L” Dimension
CPM-_ _ _ _ -3411_ - _ _
79.70 [3.138]
CPM-_ _ _ _ -3421_ - _ _
98.52 [3.879]
CPM-_ _ _ _ -3432_ - _ _
117.52 [4.627]
CPM-_ _ _ _ -3441_ - _ _
136.70 [5.382]
Note: Shaft key not included with motor Key available through McMaster-Carr Part Number: 96717A181 Description: Metric shaft key Dimensions: 5mm x 5mm x 20mm
Shaft Keyway Detail
[20]
.787
[5]
.197
[3]
.118
[5]
.197
3.18
.125
For #6 or M3.5 thread-cutters
Use to mount optional 60mm x 60mm fan.
(3X)
